Autel Autolink Al519 Obd2 Scanner Enhanced Mode 6 Diagnoses

Descripción

Autel Robust AL519 OBD2 Scanner For Workshops And DIYers - For Ready Test(Yearly Smog Check), Component Test, Live Data, Turn Off Check Engine Lights

utel AutoLink AL519 OBDII/EOBD Scanner supports all 10 modes of OBDII test for a complete diagnosis. Featuring the unique patented One-Click I/M Readiness Key, TFT color display and built-in speaker, the AutoLink AL519 is truly the ultimate in power and affordability, allowing users to do their jobs faster. In addition, thousands of troubleshooter code tips(DTC Library/ DTC Lookup) help technicians to save diagnosis and repair time.

Key Features:

Robust materials made, longer life than other code reader.
Huge size and ergonomic anti-slip body design - Perfect for a day-long use.
Plug & Play scanner
Patented One-Click Readiness Key/ Ready Test
Battery-free scan tool
Retrieve vehicle information/ DTC library/ DTC Lookup
View Live Data/ Recording Data/ Playback Data/ Print Data(Windows-PC).
Turn Off Check Engine Light(MIL)
Read/Clear codes and resets monitors
O2 monitor test, On-Board Monitor Test, Component Test
Mulitilingual for different aera use/ Lifetime free updates(Windows-PC).
Works with most OBDII & CAN compliant vehicles US post 1996, EU post 2006, Asian post 2009.
NOTE: 1. AL519 softwares updating only supports Windows-based PC , does not support MAC. 2.Autel AL519/ ML519 is the basic obd2 code reader, no need to and can't be registered, thought the softwares are updatable. Any questions or need any tech-support, please feel free to write us.

Full OBDII Functions - All-In-One OBD2 Diagnostic Scan Tool for It's Job.

Ready Test: This function can be used as a convenient readiness test tool by automotive technicians to determine if the tested vehicle is ready for an emission test. By visual and audible indication, you will learn a vehicle’s monitors readiness.

Ready Test APP & One Button I/M Readiness: The purpose of this function is to indicate which of the vehicle’s monitors have run and completed their diagnosis and testing, and which ones have not yet run and completed testing and diagnosis of their designated sections of the vehicle’s emission system. All data shows on one screen, which provides a simple profile of vehicle at a glance, saving diagnosis time and improving technician productivity.

As Post-repair Diagnostic Tool: This function can be used (after the vehicle has done any emission-related repairs) to confirm that the repair has been

performed successfully. After repairs, some drive cycles are required to reset the monitoring systems. Drive cycles vary among vehicles and for each monitor in any particular vehicle.

As Pre-check Diagnostic Tool: Prior to having a vehicle inspected for compliance to a state emissions test, you could use this function to check the readiness status first by yourself.

NOTE: This function reads off the real time data of emission-related monitoring systems readiness status. Once the scan tool has finished other operations, for example, clearing trouble codes, the I/M Readiness Monitor Status program resets status of all the monitors to “INC” condition. In order to set these monitors to a Ready status, the vehicle must be driven through a complete drive cycle. Times for reset vary depending on vehicle. Please refer to your vehicle’s service manual for drive cycle information.

NOTE: In this function, only ESC button is available. The other buttons are disabled to prevent misoperation.

Review Live Data & Recording Data & PlayBack Data
1.View Data function: allows viewing of live or real time PID data of vehicle’s ECU module(s).

Viewing Complete Data Set/ View live PIDs
Viewing Custom Data Set/ view customized PID data
2. Recording Data: The Record Data function allows recording vehicle modules’ Parameter Identification (PID) data to help diagnose intermittent vehicle problems. A recording includes 5 frames of live data before trigger event and several frames after trigger event.

3. Playback Data: allows viewing of previously stored PID data.

One Click I/M Readiness Display
One click I/M Readiness function is used to check the operations of the Emission System on OBD2 compliant vehicles. It is an excellent function to use prior to having a vehicle inspected for compliance to a state emissions program.

DTC Look-up/ DTCs Library - Convenient & Save You Time
The DTC Lookup function is used to search for definitions of DTCs stored in the DTC library and for code breaker information.

Plug & Play Scanner - Easy To Use For Everyone
Autel Autolink AL519 is a Plug and Play OBD2 scan tool, provide you professional and easy to use experience.

Robust Body - For All Kinds of Working Condition
Since designed for workshops and home DIYers, Autel AL519 is upgraded from Autel AL319 from hardwares to comprehensive softwares. An all-in-one obd2 scan tool for it's job!

Extensive Vehicle Coverage
Autel AL519 supports tens of OBDII compliant portocols. And supports cars: US post-1996, EU post-2006, and Asian post-2009.
Retrieves generic (P0, P2, P3, and U0), manufacturer specific (P1, P3, and U1) codes and pending codes
Autel al319

Data Print- Need Windows-Based PC
As a workp professional obd2 code reader, AL519 scanner supports data printing via Windows-based PC for later customer later analysis.

Lifetime Updates
Unlike like other softwares-fixed obd2 scanner, Autel AL519 supports lifetime softwares updates for language/ DTC library or softwares improvement purposes.

Multilingual For Different Working Aeras
Autel AL519 is a multilingual scan tool. It comes with Softwares language in one of below:

1. English + German + French; 2. English + German + Dutch; 3. English + French + Spanish; 4. English + Dutch+ Spanish; 5. English + Swedish; 6. Dutch + Polish+ Italian

If the scan tool comes without your target language, but your languages are included in abve 6 options, you can download "MaxiLinkII" on Autel web to update the softwares. PS: If need any asistance, please feel free to write us.
