Descripción
Compact size, additional accessories are required to start this product: CDI kit, spark plug, start ESC, simulator, 11.1v T plug battery. 7.4vT plug battery(The above products are not included in this product ); these accessories are not exclusive accessories, are universal products, others accessories for similar products can also be used in this product
Speed: 2200-10500rpm, Piston stroke: 17.00mm; Cylinder diameter: 16.60mm Displacement: 3.5cc, Power: 0.5ps
If you use gasoline above No.92, the gasoline needs to be proportioned to the oil. The oil is 2T (2-stroke engine oil, the type used for ordinary motorcycles), which is adjusted from 1:25 to 1:30. A litre of petrol needs 40ml of oil (not included)
Operation Method: The ignition part is 7.4v battery connected to the CDI kit and then connected to the spark plug and then connected to the engine. The fuel part is the fuel tank connecting the oil pipe and the engine is connected. The starting part is the CDI kit and the kit is equipped with the Hall sensor and the engine
The product is suitable for 1:10, 1:12, 1:14 scale model cars or model ships and other equipment, also can be used for classroom display, as teaching. Notes: Please use it carefully during operation. Do not touch the motor fan with your hands to avoid scratching.
size: 99.2 x 86.6 x 97.8mm
Material: Aluminum alloy + alloy steel
colour: black
Package Contents:
1 x Engine main body
1 x Start motor + ten-tooth adapter
1 x Exhaust pipe
7 x fan blades
1 x Start belt
1 x Motor bracket gasket
2 x Motor fixing screws
1 x Hall sensor bracket
1 x Hall transmission bracket sleeve
1 x Sensing bracket fixing screw
1 x Chinese-English Instruction
Only the above package content, other products are not included.
Note: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
