Kramer 50-80022090 Tp-580r Hdmi , Bidirectional Rs-232 & Ir

Descripción

e isa 4K UHD, twisted pair receiver for HDMI, bidirectional RS-232 and IR signals. It supports resolutions up to
UHD ( 4:2: 0). The TP-580T converts HDMI, RS-232, and IR signals into a twisted pair signal that it transmits to a receiver. The converts the twisted pair signal back into HDMI, bidirectional RS-232 and IR signals.
Features: Resolution Support. - Up to
UHD ( 4:2: 0). Max. Data Rate - 10.2G bps ( 3.4G bps per graphic channel). HDTV Compatible. HDCP Compliance. HDBase
TT Technology. HDMI Support - Deep Color, x. v. ColorT, Lip Sync, HDMI Uncompressed Audio Channels, Dolby True
HD, DTS-HD, CEC. 3D Pass-Through. EDID Pass
Thru - Passes EDID signals between the source and display. Bidirectional RS-232 & IR Interface. - Commands and data can flow in both directions via the RS-232 interface, allowing status requests and remote control of the destination unit. System Range - 70m (230ft) @1080p, 40m (130ft) @4K. Cable - For optimum range and performance using HDBase
TT, use Kramer's BC-HDKat6a cable. Note that the transmission range depends on the signal resolution, source and display used. The distance using non-Kramer CAT 6 cable may not reach these ranges. Indicators - Status LEDs for input, output, link and power. Compact Digi
TOOL
Sr - 3 units can be rack mounted side-by-side in a 1U rack space with the optional RK-3T universal rack adapter.
Specifications:
INPUTS: 1 twisted pair RJ-45 connector.
OUTPUTS: 1 HDMI connector.
PORTS: 1 IR on a 3.5 mm mini jack, 1 RS-232 on a 9-pin D-sub connector.
BANDWIDTH: 10.2G bps ( 3.4G bps per graphic channel).
RS-232 BAUD RATE: 115200.
COMPLIANCE WITH HDMI STANDARD: Supports HDMI and HDCP.
POWER CONSUMPTION: 12V DC, 430mA.
OPERATING TEMPERATURE: 0° to 40°C (32° to 104°F).
STORAGE TEMPERATURE: -40° to +70°C (-40° to 158°F).
HUMIDITY: 10% to 90%, RHL non-condensing.
PRODUCT DIMENSIONS: 12.00 cm x 7.15 cm x 2.44 cm ( 4.72 x 2.81 x 0.96 ) W, D, H
PRODUCT WEIGHT: 0.2 kg ( 0.4 lbs) approx.
SHIPPING DIMENSIONS: 15.70 cm x 12.00 cm x 8.70 cm ( 6.18 x 4.72 x 3.43 ) W, D, H
SHIPPING WEIGHT: 0.7 kg ( 1.6 lbs) approx.
INCLUDED ACCESSORIES: 2 power supplies.
OPTIONS: RK-T2B 19 rack mount, Kramer external
IR sensor (P/N: 95-0104050), Kramer
IR emitter cable (P/N: C-A35/IRE-10), Kramer BC-HDKat6a cable

Sin garantía
